Glamox AquaSignal ITNSL-01TP NL95 MAIN UNIT Navigation Light Controller

SKU:
GL02-04-211
  • 02-04-211_MainImage
  • 02-04-211_AdditionalImage_1
  • 02-04-211_DimensionImage
€7,250.00

Description

The Glamox AquaSignal ITNSL-01TP NL95 Main Unit Navigation Light Controller is a reliable, high-quality control unit designed for managing navigation lights on marine vessels. As the central component of the NL95 series, this main unit provides comprehensive control and monitoring of navigation lights, ensuring compliance with maritime safety standards. It is designed for seamless integration with other modules in the NL95 series, enabling precise and efficient operation of navigation lights in all conditions. Built to withstand the rigors of marine environments, the ITNSL-01TP is durable and engineered for long-lasting performance, making it an essential part of any vessel’s navigation light system.

NL95 is a touch screen navigational light controller, which enables configuration of the navigational light system onboard the ship, after installation. The controller consists of a 7 inch TFT color display with touch panel. A dimming function is provided to reduce screen brightness to adjust for night vision on the bridge.

MIR LEDMIR LEDMIR LEDMIR LEDMIR LEDMIR LEDMIR LED

Electrical Data

  • Mains current: 0.54A

Technical Data

  • IP classification: 20

Housing

  • Main body material: Steel
  • Body colour: GR - Grey
  • Main body colour name: Dark grey

Dimensions

MIR LED

  • Length (mm): 225
  • Height (mm): 185
  • Depth (mm): 75
  • Cut out (mm): 210 x 155
  • Net weight (kg): 2.02

Certificates

  • Certification: CSS, DNV
  • Marine Approved: Yes

Light Technical Data

  • Light source included: No
