Racor Snapp Diesel Fuel Filter 30 Micron 23106-30

The Racor Snapp Diesel Filters in 30 Micron are perfect as a fuel filter for all engines up to 140hp. The 30 Micron Fuel Filter is often used as 'Pre' or 'Primary' Filter and can be used with fuel directly from the tank. Once filtered through, you may also need a 10 micron filter before entering the engine. Please consult your engine manufacturer for more details (or call us on +353 28 23190).

The one piece filter unit is designed to fit into the fuel line while being mounted into a separate dedicated mount included in this pack. Once mounted using 3 x 8mm hex head bolts, you can connect the fuel line (sold separately) between the fuel tank and diesel engine. Suits 3/8" (10mm) fuel line. Suits bio-diesel and regular diesel.

The clear bowl at the bottom of the filter will slowly fill up with water over time and can be drained using the screw valve.

Features

Specifications

• Maximum Flow Rate:  26 gph (100 lph)
• Horsepower Range: Universal up to 140 hp
• Micron: 30
• Height 7.8" (198 mm) Width 3.8" (97 mm) at bracket Depth 4.1" (104 mm)
• Water Sump Capacity 3.4 oz. (100 ml)
• Body Material: Nylon 6 plastic
• Bracket Material: Coated Steel
• Port Size 3/8" (9.5 mm)
• Quick-Connect 3/8" (9.5 mm) (per SAE J2044)
• Rated Pressure 50 PSI (3.5 bar)

Installation

Contents

1 x Racor 30 Micron Diesel Fuel Filter

1 x Racor Snapp Filter Mount

2 x Quick Connect 3/8" Hose Adapters
