Description
Fusion's plug and play all-in-one solution to the marine stereo. The Panel-Stereo from Fusion allows you to enjoy quality audio on board your boat from the convenience of a single unit – designed to save time and money with a quick and simple installation.
Features
- Preconfigured Digital Signal Processing (DSP) technology for a superior listening experience.
- Hi-Fi audio reproduction through preconfigured DSP.
- Built-in Class-D amplifier delivers higher efficiency and greater output.
- Optimally tuned, sealed enclosure with two 3-inch speakers and passive bass radiator.
- Multiple mounting options available, including flush, flat and surface mounting.
- Control your music from a compatible smart device or Garmin watch.
- IP65 Waterproof Rating
In the Box
- Fusion® Panel-Stereo
- Stereo trim
- Six 6-gauge, self-tapping stainless-steel screws
- Power wiring harness
- Documentation
Specifications
| Physical dimensions (HxWxD) | 6.10″ x 13.54″ x 1.97″ (155 x 344 x 50 mm) |
| Weight | 2.54 lb (1.15 kg) |
| Water rating | IP65 (excluding rear connectors) |
| Power input | 10.8-16 VDC |
| Operating temperature range | 32° to 122° F (0° to 50° C) |
| Current (max.) | 10 A |
| Fuse | 10 A |
| Bluetooth wireless range | Up to 30 ft. (10 m) |
| ANT wireless range | Up to 10 ft. (3 m) |
| Wireless frequencies/protocols | Bluetooth 2.4 GHz @ +9 dBm nominal ANT 2.4 GHz @ +9 dBm nominal |
| Compass-safe distance | 7.6' (229 mm) |
Stereo features |
|
| Built-in amplifier | Class-D |
| Peak power | 140 W |
| Rated power output | 43 W rms x 2 @ 14.4 V input < 1% THD |
| Built-in Digital Signal Processing | Yes |
| Fusion-Link™ control | Yes (smartphone and Garmin watch) |
| Bluetooth wireless technology | Yes |
| ANT wireless technology | Yes |
| Language | Dutch/English/French/German/Italian/Japanese/Mandarin Chinese/Spanish |
| Software updates | USB |
| Warranty | 1 year |
Sources |
|
| Sources | AM/FM/Bluetooth/USB audio/iPhone/iPod/AUX x2/AOA |
Connectivity |
|
| Auxiliary input | Two RCA inputs (AUX1, AUX2) |
| USB 2.0 | One USB 2.0 port |
| AM/FM radio | One Motorola antenna connector port |
| Line out | 1 RCA output (AUX) |
